Indoor Relative Humidity Sensor - URI

? Humidity typical range: 0 ~ 100%Rh
? Resolution: 0.1%
? Accuracy: ?± 2% f.s.?
? Humidity response time?: < 90sec (10 ~ 80%RH)?
? Type of transducer?: capacitive?
? Signal out?: 0 - 1 Vdc, 4 - 20mA?
? Working conditions?: -40 ~ +60°C?
? Power supply?: 10 ~ 30Vdc?

Model Number: URI
Data Sheet:

Quantity:: - +

Inquire Now Add to cart

Mouse over image to zoom

Product Specification

URI?Indoor Humidity Sensor?DESCRIPTION
Sensor made of plastic material for the measurement of indoor humidity. Its small size allows use in hidden conditions.?

Sensor made of a thin film that changes the capacity in linear mode with the air humidity and can be interfaced to a wireless transmission module that uses the ZigBee protocol in such a way is possible the creation of a network consisting of several sensors, directly acknowledged by a datalogger series TMF100 or TMF500 Nesa using appropriate gateway.

Available with electrical signal output in voltage (0 - 1Vdc) or current 4-20mA.

URI?Indoor Humidity Sensor?Highlighted specs
? Accurated and reliable Air Humidity Sensor
? Very limited dimensions and weight
? According to CE norms
? Ideal for wireless network using ZigBee modules

URI?Indoor Humidity Sensor?Technical Data

Humidity typical range	0 ~ 100%Rh
Resolution	0.1%
Accuracy	± 2% f.s.
Humidity response time	< 90sec (10 ~ 80%RH)
Type of transducer	capacitive
Signal out	0 - 1 Vdc, 4 - 20mA
Working conditions	-40 ~ +60°C
Power supply	10 ~ 30Vdc
Current consumption	< 0.1W
Weight	<80g

URI?Indoor Humidity Sensor?Order Form

Sensor	Indoor Relative Humidity Sensor	URI	A B	05 10 xx	ZBS1a
Output	0 ~ 1Vdc 4 ~ 20mA with option MCS module
Accessories	CS05 – Cable 5m sensor-datalogger 05? CS10 – Cable 10m sensor-datalogger 10? CSxx – Cable xx* m length sensor – datalogger
	ZBS1a - Single-channel ZigBee module for low-power sensors, complete with antenna and power supply system, separated between radio and sensor, with lithium batteries 3.6 Vdc / max19Ah (typical autonomy 3yrs).
