Pressure & Temperature Integrate Transmitter - JQWY

? Pressure Measuring range: 0～110kPa
? Temperature Measuring range: 0°C～50°C
? Power supply: DC 24V (18V～32V)
? Environment temperature: 0°C～50°C
? Pressure Response time: ≤ 50ms
? Temperature Response time: ≤ 2s
? Hysteresis and repeatability: ± 0.2％F.S
? Nonlinear: ± 0.2％F.S

  • Model Number: JQWY
Quantity:
- +
  • Pressure & Temperature Integrate Transmitter
  • Pressure & Temperature Integrate Transmitter
Mouse over image to zoom
Share:

Product Specification

JQWY Pressure & Temperature Integrate Transmitter Introduction
Suitable for all kinds of environment atmospheric pressure and temperature combined measurement.

JQWY Pressure & Temperature Integrate Transmitter Characteristic
? Have good stability for a long time
? Have intelligent digital circuit compensation and wide usage temperature
? Prevent surge voltage and reverse polarity protection
? Have anti-jamming design
? High sensitivity and low temperature drift
? Can match LCD  at site

JQWY Pressure & Temperature Integrate Transmitter Parameters

Measuring range Pressure: 0～110kPa
Temperature: 0°C～50°C
Power supply DC 24V (18V～32V)
Accuracy  Pressure: ± 0.25％
Temperature: ± 1°C
Load capacity ≤ 500Ω
Environment temperature 0°C～50°C
Response time Pressure ≤ 50ms
Temperature ≤ 2s
Hysteresis and repeatability ± 0.2％F.S
Long-term stability ± 0.1％F.S/y
Nonlinear ± 0.2％F.S
Thermal zero drift ± 0.02％F.S/°C
Over load pressure two times of range
Electrical connection cable
Measuring medium air
